Are you looking for a robust and efficient power module for your electronics projects? The Mitsubishi CM300DY-12H IGBT module is an excellent choice for both beginners and seasoned engineers. In this article, we’ll explore the key features and specifications of the CM300DY-12H.
CM300DY-12H Key Features
The Mitsubishi CM300DY-12H IGBT module is designed to deliver exceptional performance in a variety of high-power applications.
- High Current Capacity:
- High Voltage Capability: With a collector-emitter breakdown voltage of up to 600V, it can manage high-voltage operations effectively.
- Efficient Power Handling.
- Low On-State Voltage: Featuring a low Vce(on) of 2.8V at 15V and 300A, the CM300DY-12H ensures minimal power loss during operation.
- Chassis Mount: Designed for easy mounting, this module can be securely attached to a chassis, enhancing stability and heat dissipation.
Technical Specifications
To give you a clearer picture of what the Mitsubishi CM300DY-12H IGBT module offers, here are its detailed technical specifications:
ParameterValueCategoryDiscrete Semiconductor ProductsFamilyIGBTs – ModulesSeriesIGBTMOD™ConfigurationHalf BridgeVoltage – Collector Emitter Breakdown (Max)600VCurrent – Collector (Ic) (Max)300APower – Max1100WVce(on) (Max) @ Vge, Ic2.8V @ 15V, 300ACurrent – Collector Cutoff (Max)1mAInput Capacitance (Cies) @ Vce30nF @ 10VInputStandardNTC ThermistorNoMounting TypeChassis MountPackage / CaseModuleDescription300A/600V/IGBT/2U; IGBT MOD DUAL 600V 300A H SERApplications
The Mitsubishi CM300DY-12H IGBT module is versatile and can be used in various high-power applications, including:
- Inverters: Ideal for power inverters in renewable energy systems such as solar and wind power installations.
- Motor Drives: Suitable for industrial motor drives requiring high current and voltage handling capabilities.
- Power Supplies: Excellent for use in high-power AC-DC and DC-DC power supplies.
- Electric Vehicles.
- UPS Systems: Reliable choice for uninterruptible power supply (UPS) systems, ensuring continuous power delivery.
Why Choose the Mitsubishi CM300DY-12H?
For beginners and professionals alike, the Mitsubishi CM300DY-12H IGBT module offers several advantages:
- Reliability: Mitsubishi’s robust design ensures long-lasting performance and reliability in demanding environments.
- Efficiency: With low on-state voltage and high power dissipation, this module maximizes efficiency in power conversion and management.
- Ease of Use: The chassis mount design simplifies installation, making it accessible even for those new to power electronics.
